    Sand And Slurry Jet Suction Dredger For Mining

    Ask Lasest Price
    Brand Name : yongsheng
    Model Number : ys-16inch
    Price : 95000usd/piece
    Payment Terms : T/T,L/C
    Supply Ability : 100piece/Year
    Delivery Time : 30 work days
    • Product Details
    • Company Profile

    Sand And Slurry Jet Suction Dredger For Mining

    Sand and Slurry Jet Suction Dredger for Mining

    1.Brief Introduction

    Jet Suction sand dredgers is widely used to recover underwater materials from great depths and can also extract

    sand from below a clay overburden. The jet suction sand dredgers is also called suction sand dredgers. The jet

    suction sand dredgers is equipped with high pressure water pump and powerful sand suction pump. The water

    pump can produce high pressure high speed water jet to impact the bottom of sand layer and splashing the mixed

    sand around the suction head, and the sand suction pump conveys the sand to the destination through the

    discharge pipe.


    Sand And Slurry Jet Suction Dredger For Mining

    Product Paramenters:
    Model
    Soild
    capacity
    Water flow
    Dredging depth
    Discharge distance
    Main engine
    Auxiliary engine
    Total consumption
    size(m)
    6inch
    40-50
    m3/h
    250
    m3/h
    6M
    500M
    120
    KW

    18L/H
    10*3.8*1.6
    8inch
    80-100
    m3/h
    500
    m3/h
    8M
    500M
    176
    KW
    60KW
    40L/H
    14*4.5*1.2
    10inch
    150-180
    m3/h
    900
    m3/h
    10M
    800M
    294
    KW
    88KW
    60L/H
    17*5*1.2
    12inch
    200-250
    m3/h
    1400
    m3/h
    10M
    1000M
    456
    KW
    110KW
    80L/H
    20*6*1.5
    14inch
    300-400
    m3/h
    2000
    m3/h
    12M
    1500M
    735
    KW
    120KW
    120L/H
    24*6.6*1.6
    16inch
    400-500
    m3/h
    2600
    m3/h
    14M
    1500M
    882
    KW
    258KW
    150L/H
    24*7.2*1.8
    18inch
    500-600
    m3/h
    3000
    m3/h
    14M
    1500M
    1103
    KW
    456KW
    220L/H
    24*7.6*2.0
    20inch
    600-700
    m3/h
    3800
    m3/h
    14M
    1500M
    1250
    KW
    456KW
    240L/H
    26*7.6*2.0
    Note: Because this equipment is a customized product, the maximum conveying distance of one pump is 1000-2000m. If long-distance conveying is required, a separate relay pump group is added.
    The above output is calculated based on the conventional flow rate 15-20% concentration. If the long-distance conveying concentration will be reduced, it can be calculated based on about 15% of the flow rate.




























    Sand And Slurry Jet Suction Dredger For Mining

    Sand And Slurry Jet Suction Dredger For Mining

    Sand And Slurry Jet Suction Dredger For Mining


    Advantage:


    Novel design, High efficient, large output, long discharge distance.
    High quality wear resistance and long serve life sand pump.
    Pumping depth reaches up to 20-30m underwater.
    Dredge hull consists of multiple pontoons connected by proven coupling system.
    Highly efficient fuel consumption and minimum overall operational costs.
    Control box and instrument are mounted in ergonomic dash board.
    Low investment and good operating performance.
    Simple and fast assembly and disassembly, easy to operate.
