    Low Speed Sand Dredger Machine for Riverbed Sand Mining with a Clear Water Flow Rate of 3500m ³ and a 18 inch Conveying

    Ask Lasest Price
    Brand Name : yongsheng dredger
    Model Number : YSCSD450
    Certification : CCS
    Price : 300000-1000000 US Dollars
    Payment Terms : L/C, T/T
    Supply Ability : 30 sets per year
    Delivery Time : 50 days
    • Product Details
    • Company Profile

    Low Speed Sand Dredger Machine for Riverbed Sand Mining with a Clear Water Flow Rate of 3500m ³ and a 18 inch Conveying

    Low Speed Sand Dredger Machine for Riverbed Sand Mining with a Clear Water Flow Rate of 3500m ³ and a 18 inch Conveying


    1. The working locations of the suction type sand dredger can be: sea, port, lake, pond or river.


    The sand dredgers we produce are diesel engine driven, self-propelled or non self-propelled, portable hydraulic twist suction sand dredgers. The hull adopts a detachable and box shaped structure, which can be disassembled for transportation and assembled at the work site.

    It can also be equipped with anchor rods and pile supports to increase capacity.


    2. Special requirement for cutter suction dredger can be custom building

    Standard Model list for hydraulic cutter suction dredger
    ModelInchDiameter pipeWater flowSolid capacityTotal powerDredging depth

    Discharge

    distance

    YSCSD1506 Inch150 mm260 m3/h30 cbm/h102 KW4 m600 m
    YSCSD2008 Inch200 mm600 m3/h80 cbm/h213 KW6 m800 m
    YSCSD25010 inch250 mm1,000 m3/h160 cbm/h367 KW8 m1,100 m
    YSCSD30012 inch300 mm1,500 m3/h240 cbm/h591 KW10 m1,100 m
    YSCSD35014 inch350 mm2,400 m3/h360 cbm/h971 KW12 m1,200 m
    YSCSD40016 Inch400 mm3,000 m3/h500 cbm/h1,057 KW14 m1,400 m
    YSCSD45018 Inch450 mm3,500 m3/h700 cbm/h1,462 KW15 m1,500 m
    YSCSD50020 Inch500 mm3,800 m3/h760 cbm/h1,648 KW15 m1,600m
    YSCSD60024 Inch600 mm6,000 m3/h900 cbm/h2,511 KW15 m1,800 m
    YSCSD65026 Inch650 mm7,000 m3/h1,400 cbm/h3,705 KWMax.18m1,800m

    3. Our factory produces twisted suction sand dredgers

    4. Technical Specification for YSCSD450 Hydraulic Twisted Suction Sand Extraction Ship with Actual Ship Capacity of 700cbm/h

    YSCSD450 solid capacity 500 cbm/h hydraulic cutter suction dredger
    Technical specifications
    Water flow3,500 m3/h
    Solid capacity700 cbm/h
    Max. dredging depth 45°15 m
    Discharge distance1,500 m
    LOA43.5 m
    Dredger after assembly43.5*7.5*2 m Length* width* depth
    Dredger structureDismantle type and can be assembly in working site
    Average draught1.2 m
    Diameter discharge pipe450mm/18 inch
    Main Engine1,007 kw Cummins engine
    Rotate speed1800 r/min
    Auxiliary engine power425 kw Cummins engine
    Generator30 kw
    Hydraulic cutter power160 kw
    Total power1,057 kw

    5. Overall layout of a complete set of twisted suction sand dredgers


    Composition of the system

    ——One main engine pontoon

    ——Two side pontoons

    ——Connected devices of floating pontoon

    ——Upper structures

    ——Equipment base and special strengthen devices and equipments


    6. Working conditions for sand pumping boats


    The Maximum Temperature 500C

    The Minimum Temperature -100C

    The Maximum Temperature of engine room 500C

    The Maximum Temperature of The River (Sea) Water 300C

    The Relative Humidity ≤80%
