Diesel Engine Power 1,864KW Customize Accepted Versatile Sand
Dredger for Dredging in Different Water Conditions
Product Description:
With a cutter head diameter of 1.5m, this sand dredger can quickly
and effectively excavate large
quantities of sand or mud, making it an ideal choice for a wide
range of applications. Whether you're working
on a river, lake, or sea, this sand dredger can help you get the
job done quickly and efficiently.
In addition to its powerful performance and innovative design, our
sand dredger is also highly customizable.
We understand that every project is different, which is why we
offer a wide range of customization options
to ensure that our sand dredger meets your specific needs and
requirements. Whether you need to
modify the size, shape, or function of your dredger, we're here to
help you get the most out of your investment.
So if you're in the market for a top-quality sand dredger for sale,
look no further than our Sand Dredger
product. With its powerful performance, innovative design, and
customizable options, this dredger is the
perfect choice for any project, no matter how big or small.
| Model list for hydraulic cutter suction dredger |
| Model | Inch | Diameter pipe | Water flow | Solid capacity | Total power | Dredging depth | Discharge distance |
| YSCSD150 | 6 Inch | 150 mm | 260 m3/h | 30 cbm/h | 102 KW | 4 m | 600 m |
| YSCSD200 | 8 Inch | 200 mm | 600 m3/h | 80 cbm/h | 213 KW | 6 m | 800 m |
| YSCSD250 | 10 inch | 250 mm | 1,000 m3/h | 160 cbm/h | 367 KW | 8 m | 1,100 m |
| YSCSD300 | 12 inch | 300 mm | 1,500 m3/h | 240 cbm/h | 591 KW | 10 m | 1,100 m |
| YSCSD350 | 14 inch | 350 mm | 2,400 m3/h | 360 cbm/h | 971 KW | 12 m | 1,200 m |
| YSCSD400 | 16 Inch | 400 mm | 3,000 m3/h | 500 cbm/h | 1,057 KW | 14 m | 1,400 m |
| YSCSD450 | 18 Inch | 450 mm | 3,500 m3/h | 700 cbm/h | 1,462 KW | 15 m | 1,500 m |
| YSCSD500 | 20 Inch | 500 mm | 3,800 m3/h | 760 cbm/h | 1,648 KW | 15 m | 1,600m |
| YSCSD600 | 24 Inch | 600 mm | 6,000 m3/h | 900 cbm/h | 2,511 KW | 15 m | 1,800 m |
| YSCSD650 | 26 Inch | 650 mm | 7,000 m3/h | 1,400 cbm/h | 3,705 KW | Max.18m | 1,800m |
Features:
- Product Name: Sand Dredger
- Dredging depth: 15 M
- Material: CCS Marine Using Plate
- Working Capacity: Maximum 1400 Cbm/h
- Work Site: River, lake, sea
- Custom building: Accepted
Sand dredger machinery from Yongsheng Dredger. The Sand Dredger is
a custom-built ship used
for sludge dredging underwater, capable of operating in rivers,
lakes, and seas.
Applications:
CCS or Panama certificate for Cutter suction dredger from Yongsheng
dredger is available
The dredger can work for land filling, sand dredging, port
deepening, channel dredging and land reclamation.
The design, construction, quality inspection of our cutter suction
dredger is based on the standards and regulations of CCS. The hull,
machinery equipment and other spares are at the requirements of CCS
as well. The hull is square, cross keel, which is full welding
steel structure, and authorized by CCS.
The dredgers we are producing are diesel engine driven,
self-propelled or non self-propelled, portable hydraulic cutter
suction dredgers. The hull uses dismantle and box-like structure,
dismantle for shipment and assembly at working site.
It can also be equipped with anchoring poles and spud carrier to
increase capacity.
FAQ:
Q: What is the brand name of this dredger?
A: The brand name of this dredger is Yongsheng dredger.
Q: What is the model number of this dredger?
A: The model number of this dredger is YSCSD650.
Q: Where is this dredger made?
A: This dredger is made in China.
Q: Does this dredger come with any certifications?
A: Yes, this dredger comes with CCS certification.
Q: What is the minimum order quantity for this dredger?
A: The minimum order quantity for this dredger is 1.
Q: What is the price of this dredger?
A: The price of this dredger is custom building. Please contact us
for more information.
Q: How is this dredger packaged?
A: This dredger is packaged in bulk.
Q: What is the delivery time for this dredger?
A: The delivery time for this dredger is 60-90 days.
Q: What are the payment terms for this dredger?
A: The payment terms for this dredger are 30% deposit and 70% final
payment.
Q: What is the supply ability for this dredger?
A: The supply ability for this dredger is 30 sets per year.
